Commercial Duo Series
High-efficiency commercial heat pump with eco-friendly R290 refrigerant — heating, cooling and DHW up to 78 °C, reliable down to -25 °C ambient.
- R290 Eco-Friendly Gas - Natural refrigerant for high efficiency and sustainable performance.
- 78 °C Water Outlet Temperature - Ideal for industrial process and high-temperature heating.
- -25 °C Operation Capability – Efficient operation in harsh outdoor conditions.
- A+++ energy class with excellent COP / EER values for reduced operating costs.
- Low sound pressure levels for professional environments.
Industrial R290 Heat Pump
The Commercial Duo Series provides high-efficiency heating, cooling and hot water using the environmentally friendly R290 refrigerant. It operates reliably at low ambient temperatures down to -25 °C, provides hot water up to 78 °C and covers a wide range of capacities to meet commercial and industrial needs.
With A+++ energy class and excellent COP / EER values, the series maximizes efficiency and reduces operating costs. Durable construction and low sound pressure levels ensure long-lasting, reliable performance in any professional environment.
General
Ambient Temp (DB/WB)
°C
7/6
Water Temp (In/Out)
°C
30/35
Heating Capacity Range
kW
18.4~49.25
Heating Power Consumption
kW
4.23~12.98
COP Range
3.8~4.3
Ambient Temp (DB/WB)
°C
20/15
Water Temp (In/Out)
°C
15/55
DHW Capacity Range
kW
23.8~68
DHW Power Consumption
kW
4.23~15.46
COP Range
4.46~5.62
Heated Water Output
L/h
1462
Ambient Temp (DB/WB)
°C
35/24
Water Temp (In/Out)
°C
12/7
Cooling Capacity Range
kW
13.8~34.5
Cooling Power Consumption
kW
5.2~16.2
EER Range
2.1~2.65
Power Supply
380-415V/3Ph/50-60Hz
Maximum Power Consumption
kW
20
Maximum Current
A
32
Fuse / Circuit Breaker
A
40
Cable Section
mm²
10
Pipe Diameter
G 1.5"
Maximum Water Flow
m³/h
8.6
Maximum Water Pressure Drop
kPa
80
Sound Power Level
dB(A)
≤77
Sound Pressure Level
dB(A)
≤62
Refrigerant
R290 / 4.0 kg
Compressor Brand
HIGHLY
IP Rating
IPX4
Anti-Electric Shock Rate
I
Net Weight
kg
370
Body Dimensions (W×D×H)
mm
1195×980×1900
Packing Dimensions (W×D×H)
mm
1275×1060×2100
Ambient Temperature
°C
-25~43
Water Temperature (DHW)
°C
20~78
Water Temperature (Heating)
°C
20~78
Water Temperature (Cooling)
°C
7~30
General
Ambient Temp (DB/WB)
°C
7/6
Water Temp (In/Out)
°C
30/35
Heating Capacity Range
kW
35.2~92
Heating Power Consumption
kW
7.0~23.8
COP Range
3.86~5.02
Ambient Temp (DB/WB)
°C
20/15
Water Temp (In/Out)
°C
15/55
DHW Capacity Range
kW
40.0~120
DHW Power Consumption
kW
9.0~29.5
COP Range
4.06~5.5
Heated Water Output
L/h
2580
Ambient Temp (DB/WB)
°C
35/24
Water Temp (In/Out)
°C
12/7
Cooling Capacity Range
kW
25~66
Cooling Power Consumption
kW
8.92~30.7
EER Range
2.15~2.8
Power Supply
380-415V/3Ph/50-60Hz
Maximum Power Consumption
kW
40
Maximum Current
A
64
Fuse / Circuit Breaker
A
80
Cable Section
mm²
22
Pipe Diameter
G 2"
Maximum Water Flow
m³/h
17.2
Maximum Water Pressure Drop
kPa
120
Sound Power Level
dB(A)
≤85
Sound Pressure Level
dB(A)
≤65
Refrigerant
R290 / 8.0 kg
Compressor Brand
HIGHLY
IP Rating
IPX4
Anti-Electric Shock Rate
I
Net Weight
kg
745
Body Dimensions (W×D×H)
mm
2510×979×1882
Packing Dimensions (W×D×H)
mm
2560×1030×2000
Ambient Temperature
°C
-25~43
Water Temperature (DHW)
°C
20~78
Water Temperature (Heating)
°C
20~78
Water Temperature (Cooling)
°C
7~30
Notes
- R290 natural refrigerant — commercial-scale efficiency with future-proof compliance.
- Three-phase 380-415V supply for both 50 kW and 92 kW models.
- Outlet water up to 78 °C for high-temperature process and DHW applications.
Contact quality@solimpeks.com for local certificates / OEM certificate duplication requests.
Understand the technology
Explainers from our Knowledge Hub on how this technology works.
Guides
Heat Pumps for Homes & Business: The Complete Guide
A heat pump moves heat from outside air, the ground or water into a building, delivering 3–5 kWh of heat per kWh of electricity —...
Glossary
COP (Coefficient of Performance)
COP (Coefficient of Performance) is the ratio of useful heat a heat pump delivers to the electricity it consumes at one fixed...
Common Questions
What size heat pump do I need for my home?
Size a heat pump to the building's calculated heat load at design outdoor temperature, not to the old boiler. Typical specific...
FAQ
Heat Pump FAQ
An air source heat pump extracts heat from outdoor air and delivers it to radiators, underfloor heating and a hot water cylinder...
Frequently asked questions
Short, factual answers about the Commercial Duo Series.
What applications suit the Commercial Duo Series?
The Commercial Duo Series is a commercial air-to-water heat pump running on natural R290 refrigerant. With outlet temperatures up to 78 °C it covers industrial process heat, commercial hot water and high-temperature heating circuits, and it keeps operating down to -25 °C outdoors.
Why R290 for a commercial unit?
R290 (propane) has a global warming potential of about 3 and is unaffected by the EU F-Gas phase-down that is squeezing HFC refrigerants out of commercial equipment. It also reaches the high outlet temperatures — up to 78 °C here — that many commercial processes demand.
What warranty does the Commercial Duo Series carry?
Solimpeks backs the Commercial Duo Series with a 2-year product warranty, stated on this product page. Commercial installations should be commissioned by a qualified installer.
